PSMCBT Temperatures Check
Summary
| Date start | 2024:295:01:24:44.616 |
| Date stop | 2024:301:21:58:15.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2024/OCT2124/oflsa |
| Run time | Thu Oct 8 16:13:59 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.41 | -2.67 | -1.82 | -0.50 | 1.14 | 1.94 | 3.02 |
| pitch | -9.623 | -0.445 | -0.004 | -0.000 | 0.004 | 0.455 | 10.236 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.861 | -0.080 | -0.007 | 0.000 | 0.009 | 0.130 | 2.536 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.41 | 2.50 |
| PITCH | 1 | -9.623 | 3.00 |
| PITCH | 99 | 10.236 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
