PSMCBT Temperatures Check
Summary
| Date start | 2023:295:18:30:47.116 |
| Date stop | 2023:302:15:21:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/OCT2323/oflsa |
| Run time | Thu Oct 8 16:14:02 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.49 | -2.92 | -2.28 | -0.72 | 0.79 | 1.70 | 2.75 |
| pitch | -10.201 | -0.778 | -0.004 | -0.000 | 0.004 | 0.474 | 10.338 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 112 |
| roll | -1.986 | -0.178 | -0.010 | 0.000 | 0.008 | 0.200 | 2.286 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.49 | 2.50 |
| PITCH | 1 | -10.201 | 3.00 |
| PITCH | 99 | 10.338 | 3.00 |
| TSCPOS | 99 | 112.0 | 2.50 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
