PSMCBT Temperatures Check
Summary
| Date start | 2024:259:23:58:32.616 |
| Date stop | 2024:267:02:31:27.316 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2024/SEP1624/oflsa |
| Run time | Thu Oct 8 16:15:12 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.77 | -3.17 | -2.41 | -0.67 | 0.81 | 1.65 | 2.50 |
| pitch | -5.862 | -0.054 | -0.004 | -0.000 | 0.004 | 0.005 | 7.361 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.504 | -0.034 | -0.004 | -0.000 | 0.003 | 0.024 | 1.140 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.77 | 2.50 |
| PITCH | 1 | -5.862 | 3.00 |
| PITCH | 99 | 7.361 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
