PSMC Temperatures Check
Summary
| Date start | 2025:153:19:50:00.016 |
| Date stop | 2025:159:23:43:43.816 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/JUN0225/ofls |
| Run time | Sun Jun 1 12:20:03 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEAAT Upper Limit Violations
PSMC Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEAAT >= 30.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeaat | -3.01 | -2.32 | -1.63 | -0.35 | 1.94 | 3.01 | 5.94 |
| pitch | -5.124 | -0.294 | -0.004 | -0.000 | 0.004 | 0.437 | 5.374 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 0 | 1 |
| roll | -1.291 | -0.116 | -0.006 | -0.000 | 0.006 | 0.126 | 1.343 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEAAT | 1 | -3.01 | 2.50 |
| 1PDEAAT | 99 | 5.94 | 5.50 |
| PITCH | 1 | -5.124 | 3.00 |
| PITCH | 99 | 5.374 | 3.00 |
1PDEAAT
Note: 1PDEAAT residual histograms include only points where 1PDEAAT >= 30.0 C in blue and points where 1PDEAAT >= 40.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
