PSMC Temperatures Check
Summary
| Date start | 2025:061:23:32:37.116 |
| Date stop | 2025:068:17:45:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/MAR0325/ofls |
| Run time | Wed Feb 26 19:09:09 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEAAT Upper Limit Violations
PSMC Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEAAT >= 30.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeaat | -3.26 | -2.08 | -1.14 | 0.24 | 1.56 | 2.38 | 4.09 |
| pitch | -7.079 | -0.634 | -0.004 | 0.000 | 0.004 | 1.206 | 7.483 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 1 | 1 |
| roll | -1.751 | -0.256 | -0.010 | 0.000 | 0.010 | 0.184 | 1.430 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEAAT | 1 | -3.26 | 2.50 |
| PITCH | 1 | -7.079 | 3.00 |
| PITCH | 99 | 7.483 | 3.00 |
1PDEAAT
Note: 1PDEAAT residual histograms include only points where 1PDEAAT >= 30.0 C in blue and points where 1PDEAAT >= 40.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
