AGASC ID 966396120

Info

Last Obs. 2022:167:11:05
magcatalog 7.74 ± 0.12
mag3 arcsec 7.82 ± 0.01
mag5 arcsec 7.82 ± 0.01
Nobs 25 (0 bad)
fok 99.9%
f3 arcsec 100.0%
f5 arcsec 100.0%

Timeline

Observation Info

OBSID Time Slot Row Col N Nmag est ok Nout fmag est ok fdr3 fdbox5 fmag est ok 3 ⟨ δ mag ⟩ 100s ⟨ mag ⟩ σmag Comments
6628 2006:185:12:45:51.619 5 -275.6 94.5 6187 6186 6 100.0% 100.0% 100.0% 100.0% 0.01 7.82 0.00 --
7336 2006:232:05:17:41.918 5 -224.2 191.7 6188 6186 4 100.0% 100.0% 100.0% 100.0% 0.01 7.82 0.00 --
12505 2011:065:00:24:07.471 5 242.4 314.4 557 556 1 99.8% 100.0% 100.0% 99.8% 0.02 7.83 0.00 --
13220 2011:186:19:56:34.722 5 -271.9 96.5 9737 9677 7 99.4% 100.0% 100.0% 99.4% 0.02 7.81 0.00 --
12405 2011:213:06:43:39.277 6 -202.2 -326.0 15324 15308 24 99.9% 100.0% 100.0% 99.9% 0.01 7.82 0.00 --
55259 2011:213:15:57:51.615 7 -202.2 -326.0 45 45 1 100.0% 100.0% 100.0% 100.0% 0.01 7.81 0.00 --
12406 2011:279:11:05:08.298 4 -295.2 -254.5 13754 13747 15 99.9% 100.0% 100.0% 99.9% 0.01 7.81 0.00 --
55140 2011:279:19:17:43.784 2 -295.2 -254.5 45 45 0 100.0% 100.0% 100.0% 100.0% 0.00 7.81 0.00 --
12199 2011:282:04:23:33.958 5 -182.7 229.4 9547 9546 9 100.0% 100.0% 100.0% 100.0% 0.01 7.80 0.00 --
55134 2011:282:10:07:04.050 3 -182.7 229.4 45 45 0 100.0% 100.0% 100.0% 100.0% 0.00 7.79 0.00 --
13222 2011:291:08:19:25.250 6 -171.7 237.8 20068 20061 15 100.0% 100.0% 100.0% 100.0% 0.02 7.80 0.00 --
14256 2012:130:08:39:02.276 6 98.7 -241.3 4968 4965 4 99.9% 100.0% 100.0% 99.9% 0.02 7.83 0.00 --
14658 2013:185:14:07:30.756 5 -93.1 -367.9 19637 19635 8 100.0% 100.0% 100.0% 100.0% 0.02 7.82 0.00 --
14659 2013:217:04:58:35.015 6 -211.4 -320.7 20279 20276 11 100.0% 100.0% 100.0% 100.0% 0.02 7.83 0.00 --
14660 2013:266:02:04:26.015 5 -278.1 -270.0 21057 21049 16 100.0% 100.0% 100.0% 100.0% 0.02 7.82 0.00 --
14661 2013:299:09:05:05.148 5 -322.9 -219.7 19564 19553 25 99.9% 100.0% 100.0% 99.9% 0.02 7.82 0.00 --
53279 2013:299:20:47:17.319 4 -322.9 -219.7 46 46 0 100.0% 100.0% 100.0% 100.0% 0.01 7.82 0.00 --
17787 2016:090:07:33:18.807 4 318.7 218.7 19968 19955 18 99.9% 100.0% 100.0% 99.9% 0.02 7.81 0.00 --
51143 2016:090:19:28:15.433 2 318.7 218.7 45 45 1 100.0% 100.0% 100.0% 100.0% 0.01 7.81 0.00 --
17788 2016:121:11:41:52.238 4 322.1 213.1 19603 19599 11 100.0% 100.0% 100.0% 100.0% 0.02 7.81 0.00 --
17789 2016:147:22:47:21.451 5 375.4 -27.0 9829 9826 7 100.0% 100.0% 100.0% 100.0% 0.02 7.83 0.00 --
18855 2016:148:17:08:14.012 5 375.4 -27.0 9783 9778 9 100.0% 100.0% 100.0% 100.0% 0.02 7.83 0.00 --
50997 2016:148:23:20:49.422 4 375.4 -27.0 31 31 1 100.0% 100.0% 100.0% 100.0% 0.00 7.82 0.00 --
18084 2016:298:02:31:25.997 6 -161.8 243.8 10810 10806 12 100.0% 100.0% 100.0% 100.0% 0.02 7.80 0.00 --
26435 2022:167:11:05:18.100 4 111.3 -357.3 14724 14714 11 99.9% 100.0% 100.0% 99.9% 0.02 7.83 0.00 --

  • sample: One sample of ACA image telemetry. This could be a real image readout or it could be a null 4x4 image when the ACA is not tracking. Be aware that the sample period is faster for null 4x4 images (1.025 sec) than for typical 6x6 or 8x8 tracked images (2.05 or 4.1 sec respectively).
  • Kalman samples: Subset of samples when ACA could be tracking stars (AOPCADMD == NPNT & AOACASEQ == KALM)
  • dr3: Subset of tracked Kalman samples with radial centroid residual < 3 arcsec. This corresponds to "high quality" readouts. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • dbox5: Subset of tracked Kalman samples with centroid residual within a 5 arcsec box. This corresponds to spatial filter used by the OBC for inclusion in Kalman filter. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • track: Subset of Kalman samples where the image is being tracked (AOACFCT == TRAK)
  • sat_pix: Subset of Kalman samples with saturated pixel flag OK (AOACISP == OK)
  • ion_rad: Subset of Kalman samples with ionizing radiation flag OK (AOACIIR == OK)
  • mag_est_ok: Subset of Kalman samples that have a magnitude estimate (track & ion_rad)
  • n_total: Total number of sample regardless of OBC PCAD status
  • n: Synonym for n_total
  • n_kalman: Number of Kalman samples
  • n_dr3: Number of dr3 samples.
  • n_dbox5: Number of dbox5 samples.
  • n_track: Number of track samples.
  • n_ok_3: Number of (track & sat_pix & ion_rad & dr3) samples
  • n_ok_5: Number of (track & sat_pix & ion_rad & dbox5) samples
  • n_mag_est_ok: Number of (track & ion_rad) samples
  • n_mag_est_ok_3: Number of (track & ion_rad & dr3) samples
  • n_mag_est_ok_5: Number of (track & ion_rad & dbox5) samples
  • f_dr3: Fraction of mag-est-ok samples with centroid residual < 3 arcsec((mag_est_ok & n_dr3)/n_mag_est_ok)
  • f_dbox5: Fraction of mag-est-ok samples with centroid within 5 arcsec box((mag_est_ok & n_dbox5)/n_mag_est_ok)
  • f_mag_est_ok: n_mag_est_ok_3/n_kalman. This is a measure of the fraction of time during an observation that a magnitude estimate is available.
  • f_mag_est_ok_3: n_mag_est_ok_3/n_kalman.
  • f_mag_est_ok_5: n_mag_est_ok_5/n_kalman.
  • f_ok: n_ok_5 / n_kalman. Same as f_ok_5
  • f_ok_3: n_ok_3 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting high-quality star centroids.
  • f_ok_5: n_ok_5 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting any star centroid at all. This includes measurements out to 5 arcsec box halfwidth, so potentially 7 arcsec radial offset.
