AGASC ID 551422208

Info

Last Obs. 2023:251:23:53
magcatalog 8.58 ± 0.13
mag3 arcsec 8.61 ± 0.02
mag5 arcsec 8.61 ± 0.02
Nobs 58 (0 bad)
fok 98.7%
f3 arcsec 100.0%
f5 arcsec 100.0%

Timeline

Observation Info

OBSID Time Slot Row Col N Nmag est ok Nout fmag est ok fdr3 fdbox5 fmag est ok 3 ⟨ δ mag ⟩ 100s ⟨ mag ⟩ σmag Comments
59550 2005:196:15:39:59.124 6 -179.9 -217.9 1809 1755 7 99.9% 100.0% 100.0% 99.9% 0.03 8.61 0.00 --
5646 2006:089:11:05:18.059 3 448.1 -88.5 1275 1198 2 99.8% 100.0% 100.0% 99.8% 0.02 8.62 0.00 --
20362 2018:207:00:31:35.103 7 -201.4 471.9 22582 22190 25 98.6% 100.0% 100.0% 98.5% 0.04 8.58 0.00 --
20361 2018:316:15:54:55.931 3 -446.3 -204.5 18471 18162 9 98.7% 100.0% 100.0% 98.7% 0.05 8.61 0.00 --
21875 2018:318:12:52:25.577 3 -446.5 -204.4 6433 6307 6 98.9% 100.0% 100.0% 98.9% 0.04 8.60 0.00 --
21959 2018:344:21:14:13.836 4 -208.6 -445.6 13608 13508 14 99.9% 100.0% 100.0% 99.8% 0.05 8.59 0.00 --
20360 2018:348:00:39:42.528 4 -208.5 -445.6 10876 10762 20 99.9% 100.0% 100.0% 99.9% 0.03 8.59 0.00 --
21650 2019:285:23:02:00.601 7 -488.9 40.0 23571 23234 9 98.9% 100.0% 100.0% 98.9% 0.07 8.62 0.00 --
21654 2020:140:09:09:48.355 3 391.0 282.2 18195 17721 23 97.7% 100.0% 100.0% 97.7% 0.04 8.60 0.00 --
23253 2020:143:01:26:32.592 3 391.1 282.2 6246 6026 5 97.4% 100.0% 100.0% 97.4% 0.03 8.60 0.00 --
21653 2020:221:00:53:35.354 7 -171.4 496.6 12347 12118 19 98.8% 100.0% 100.0% 98.8% 0.04 8.60 0.00 --
23338 2020:222:11:02:13.862 7 -172.3 497.0 9931 9641 11 97.8% 100.0% 100.0% 97.8% 0.02 8.60 0.00 --
65528 2020:238:06:42:57.286 4 -342.8 403.4 23558 23113 33 98.3% 100.0% 100.0% 98.3% 0.05 8.59 0.00 --
21651 2020:265:08:04:54.370 5 -460.9 253.7 9832 9683 13 98.5% 100.0% 100.0% 98.5% 0.04 8.61 0.00 --
21651 2020:265:08:04:54.370 5 -461.0 253.8 9896 9684 13 98.5% 100.0% 100.0% 98.5% 0.04 8.61 0.00 --
24655 2020:265:19:45:32.327 5 -460.6 253.6 6967 6788 7 98.3% 100.0% 100.0% 98.3% 0.03 8.61 0.00 --
24656 2020:266:09:09:33.203 5 -461.2 253.8 7125 6966 9 98.4% 100.0% 100.0% 98.4% 0.04 8.61 0.00 --
23016 2021:009:17:41:36.361 3 -49.8 -490.2 12336 12171 13 99.2% 100.0% 100.0% 99.2% 0.04 8.58 0.00 --
23014 2021:023:05:16:14.429 3 99.3 -480.8 13076 12732 9 98.0% 100.0% 100.0% 98.0% 0.04 8.61 0.00 --
23015 2021:086:11:21:04.238 4 473.4 -140.7 24544 24150 36 98.8% 100.0% 100.0% 98.8% 0.04 8.61 0.00 --
23013 2021:090:20:12:17.302 3 484.8 -104.9 14202 14001 14 99.2% 100.0% 100.0% 99.2% 0.04 8.61 0.00 --
22518 2021:165:00:43:39.853 5 222.5 461.4 8234 8119 12 99.7% 100.0% 100.0% 99.7% 0.03 8.61 0.00 --
25062 2021:165:16:40:04.880 5 222.1 461.5 26009 25772 24 99.4% 100.0% 100.0% 99.3% 0.06 8.60 0.00 --
22519 2021:168:08:13:29.789 5 221.4 461.9 11372 11210 19 99.2% 100.0% 100.0% 99.2% 0.03 8.60 0.00 --
24933 2021:179:14:21:18.959 4 141.6 494.0 19661 19252 5 98.3% 100.0% 100.0% 98.3% 0.10 8.61 0.00 --
25082 2021:180:15:18:47.041 3 140.5 494.5 19767 19400 8 98.4% 100.0% 100.0% 98.4% 0.06 8.62 0.00 --
23874 2021:241:15:43:24.460 3 -341.7 388.4 14548 14231 14 98.4% 100.0% 100.0% 98.4% 0.08 8.61 0.00 --
24258 2021:243:05:07:52.857 4 -308.4 414.1 9409 9237 11 98.9% 100.0% 100.0% 98.9% 0.05 8.59 0.00 --
24259 2021:246:03:53:54.387 3 -357.8 375.3 18192 17786 24 98.2% 100.0% 100.0% 98.2% 0.07 8.61 0.00 --
23875 2021:322:01:57:28.417 3 -460.2 -208.7 14397 14106 14 98.4% 100.0% 100.0% 98.4% 0.08 8.64 0.00 --
24514 2021:323:09:07:14.613 3 -457.6 -209.9 14287 14011 14 98.6% 100.0% 100.0% 98.6% 0.07 8.62 0.00 --
24515 2021:348:11:03:02.442 5 -274.3 -414.9 13800 13570 6 98.7% 100.0% 100.0% 98.7% 0.06 8.61 0.00 --
23876 2022:058:16:54:29.022 5 331.7 -362.3 14782 14443 16 98.2% 100.0% 100.0% 98.2% 0.06 8.62 0.00 --
25974 2022:074:18:19:00.950 5 390.1 -297.4 10637 10417 8 98.7% 100.0% 100.0% 98.7% 0.03 8.62 0.00 --
25975 2022:075:19:10:41.734 4 416.5 -262.0 18931 18545 17 98.3% 100.0% 100.0% 98.3% 0.09 8.63 0.00 --
23877 2022:139:04:27:37.729 6 415.0 289.9 13807 13659 20 99.4% 100.0% 100.0% 99.4% 0.03 8.61 0.00 --
25976 2022:160:12:09:54.642 4 252.3 444.7 27970 27416 15 98.3% 100.0% 100.0% 98.3% 0.08 8.61 0.00 --
23878 2022:238:19:10:07.497 5 -320.8 405.1 14631 14132 14 97.1% 100.0% 100.0% 97.1% 0.06 8.62 0.00 --
25979 2022:255:15:03:17.276 4 -419.3 301.1 14776 14596 16 99.3% 100.0% 100.0% 99.3% 0.05 8.64 0.00 --
25978 2022:262:03:56:38.949 4 -450.3 254.1 10967 10762 8 98.6% 100.0% 100.0% 98.6% 0.04 8.64 0.00 --
27451 2022:268:19:55:18.812 4 -473.6 201.4 4673 4515 3 97.9% 100.0% 100.0% 97.9% 0.03 8.64 0.00 --
23879 2022:315:02:49:44.887 7 -491.2 -134.3 6921 6801 4 99.1% 100.0% 100.0% 99.1% 0.05 8.62 0.00 --
25981 2022:324:12:41:10.717 6 -459.5 -212.2 6909 6844 1 99.6% 100.0% 100.0% 99.6% 0.11 8.61 0.00 --
25980 2022:337:19:51:06.784 4 -358.0 -350.0 3992 3866 2 98.1% 100.0% 100.0% 98.1% 0.04 8.62 0.00 --
27576 2022:338:06:27:19.499 4 -357.8 -350.0 3747 3650 1 98.6% 100.0% 100.0% 98.6% 0.03 8.62 0.00 --
25892 2023:058:12:53:28.104 5 331.4 -362.7 1637 1525 6 96.6% 99.9% 100.0% 96.5% 0.04 8.60 0.00 --
65524 2023:058:21:59:44.166 5 331.5 -362.8 8234 7923 7 97.0% 100.0% 100.0% 97.0% 0.06 8.61 0.00 --
27725 2023:064:02:15:39.601 5 376.4 -315.9 4275 4183 5 99.3% 100.0% 100.0% 99.3% 0.04 8.61 0.00 --
27726 2023:068:05:48:48.207 5 397.1 -286.1 5129 4992 3 98.7% 100.0% 100.0% 98.7% 0.04 8.62 0.00 --
23880 2023:073:21:27:17.411 4 424.8 -244.6 6569 6477 3 98.6% 100.0% 100.0% 98.6% 0.05 8.61 0.00 --
23880 2023:073:21:27:17.411 4 424.8 -244.8 6635 6477 3 98.6% 100.0% 100.0% 98.6% 0.05 8.61 0.00 --
27724 2023:074:10:29:21.550 4 428.1 -241.0 6364 6135 8 98.3% 99.9% 99.9% 98.2% 0.04 8.61 0.00 --
27724 2023:074:10:29:21.550 4 428.2 -241.2 6431 6135 8 98.3% 99.9% 99.9% 98.2% 0.04 8.61 0.00 --
27764 2023:076:21:25:07.088 4 438.3 -222.2 8732 8501 3 98.0% 100.0% 100.0% 98.0% 0.06 8.61 0.00 --
23881 2023:148:20:14:15.433 6 364.5 352.7 7413 7351 8 100.0% 100.0% 100.0% 100.0% 0.06 8.60 0.00 --
27876 2023:152:05:34:32.318 6 344.0 373.4 4975 4921 5 100.0% 100.0% 100.0% 99.9% 0.04 8.60 0.00 --
27877 2023:154:00:04:25.038 5 331.2 384.7 3995 3940 1 99.9% 100.0% 100.0% 99.9% 0.02 8.60 0.00 --
27878 2023:168:19:21:43.962 4 232.6 455.4 5734 5658 5 99.9% 100.0% 100.0% 99.9% 0.04 8.60 0.00 --
23882 2023:249:07:32:32.622 6 -356.8 374.2 6447 6391 10 100.0% 100.0% 100.0% 99.9% 0.05 8.62 0.00 --
28880 2023:250:10:59:43.475 7 -362.7 367.9 5269 5195 2 99.9% 100.0% 100.0% 99.9% 0.06 8.62 0.00 --
28882 2023:251:23:53:34.077 4 -369.8 362.1 1222 1170 0 99.8% 100.0% 100.0% 99.8% 0.04 8.61 0.00 --

  • sample: One sample of ACA image telemetry. This could be a real image readout or it could be a null 4x4 image when the ACA is not tracking. Be aware that the sample period is faster for null 4x4 images (1.025 sec) than for typical 6x6 or 8x8 tracked images (2.05 or 4.1 sec respectively).
  • Kalman samples: Subset of samples when ACA could be tracking stars (AOPCADMD == NPNT & AOACASEQ == KALM)
  • dr3: Subset of tracked Kalman samples with radial centroid residual < 3 arcsec. This corresponds to "high quality" readouts. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • dbox5: Subset of tracked Kalman samples with centroid residual within a 5 arcsec box. This corresponds to spatial filter used by the OBC for inclusion in Kalman filter. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • track: Subset of Kalman samples where the image is being tracked (AOACFCT == TRAK)
  • sat_pix: Subset of Kalman samples with saturated pixel flag OK (AOACISP == OK)
  • ion_rad: Subset of Kalman samples with ionizing radiation flag OK (AOACIIR == OK)
  • mag_est_ok: Subset of Kalman samples that have a magnitude estimate (track & ion_rad)
  • n_total: Total number of sample regardless of OBC PCAD status
  • n: Synonym for n_total
  • n_kalman: Number of Kalman samples
  • n_dr3: Number of dr3 samples.
  • n_dbox5: Number of dbox5 samples.
  • n_track: Number of track samples.
  • n_ok_3: Number of (track & sat_pix & ion_rad & dr3) samples
  • n_ok_5: Number of (track & sat_pix & ion_rad & dbox5) samples
  • n_mag_est_ok: Number of (track & ion_rad) samples
  • n_mag_est_ok_3: Number of (track & ion_rad & dr3) samples
  • n_mag_est_ok_5: Number of (track & ion_rad & dbox5) samples
  • f_dr3: Fraction of mag-est-ok samples with centroid residual < 3 arcsec((mag_est_ok & n_dr3)/n_mag_est_ok)
  • f_dbox5: Fraction of mag-est-ok samples with centroid within 5 arcsec box((mag_est_ok & n_dbox5)/n_mag_est_ok)
  • f_mag_est_ok: n_mag_est_ok_3/n_kalman. This is a measure of the fraction of time during an observation that a magnitude estimate is available.
  • f_mag_est_ok_3: n_mag_est_ok_3/n_kalman.
  • f_mag_est_ok_5: n_mag_est_ok_5/n_kalman.
  • f_ok: n_ok_5 / n_kalman. Same as f_ok_5
  • f_ok_3: n_ok_3 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting high-quality star centroids.
  • f_ok_5: n_ok_5 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting any star centroid at all. This includes measurements out to 5 arcsec box halfwidth, so potentially 7 arcsec radial offset.
