AGASC ID 111287816

Info

Last Obs. 2025:063:09:04
magcatalog 9.42 ± 0.02
mag3 arcsec 9.43 ± 0.03
mag5 arcsec 9.43 ± 0.03
Nobs 10 (0 bad)
fok 97.1%
f3 arcsec 99.9%
f5 arcsec 100.0%

Timeline

Observation Info

OBSID Time Slot Row Col N Nmag est ok Nout fmag est ok fdr3 fdbox5 fmag est ok 3 ⟨ δ mag100s ⟨ mag ⟩ σmag Comments
24440 2021:063:14:12:06.738 5 -456.4 488.3 8921 8520 11 96.1% 100.0% 100.0% 96.1% 0.09 9.43 0.00 --
24441 2021:064:04:59:28.685 5 -457.1 488.6 8435 8127 10 97.2% 100.0% 100.0% 97.2% 0.07 9.43 0.00 --
24442 2021:065:05:41:39.806 5 -456.6 488.4 9410 9016 13 96.4% 100.0% 100.0% 96.4% 0.07 9.42 0.00 --
24979 2021:065:21:12:01.296 5 -457.8 488.9 9892 9541 12 96.9% 100.0% 100.0% 96.9% 0.05 9.43 0.00 --
24980 2021:066:12:32:16.270 5 -458.9 489.5 7941 7664 12 97.0% 99.9% 100.0% 97.0% 0.05 9.42 0.00 --
23599 2021:356:03:33:20.506 5 467.3 -439.0 19663 18827 21 96.2% 100.0% 100.0% 96.1% 0.11 9.44 0.00 --
24438 2022:071:00:20:00.108 6 -463.9 479.9 7453 7194 7 97.2% 100.0% 100.0% 97.2% 0.08 9.42 0.00 --
26354 2022:071:16:40:14.571 6 -463.7 479.8 7456 7267 18 98.3% 99.8% 100.0% 98.1% 0.06 9.42 0.00 --
24439 2022:118:01:11:45.527 6 -486.9 454.9 14773 14469 12 98.3% 100.0% 100.0% 98.3% 0.13 9.40 0.00 --
42609 2025:063:09:04:17.325 6 221.1 -403.9 1963 1898 0 99.8% 95.6% 99.9% 95.4% 0.13 9.48 0.00 --

  • sample: One sample of ACA image telemetry. This could be a real image readout or it could be a null 4x4 image when the ACA is not tracking. Be aware that the sample period is faster for null 4x4 images (1.025 sec) than for typical 6x6 or 8x8 tracked images (2.05 or 4.1 sec respectively).
  • Kalman samples: Subset of samples when ACA could be tracking stars (AOPCADMD == NPNT & AOACASEQ == KALM)
  • dr3: Subset of tracked Kalman samples with radial centroid residual < 3 arcsec. This corresponds to "high quality" readouts. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • dbox5: Subset of tracked Kalman samples with centroid residual within a 5 arcsec box. This corresponds to spatial filter used by the OBC for inclusion in Kalman filter. This effectively includes the track subset (AOACFCT == TRAK) because readouts with no TRAK are assigned an infinite centroid residual.
  • track: Subset of Kalman samples where the image is being tracked (AOACFCT == TRAK)
  • sat_pix: Subset of Kalman samples with saturated pixel flag OK (AOACISP == OK)
  • ion_rad: Subset of Kalman samples with ionizing radiation flag OK (AOACIIR == OK)
  • mag_est_ok: Subset of Kalman samples that have a magnitude estimate (track & ion_rad)
  • n_total: Total number of sample regardless of OBC PCAD status
  • n: Synonym for n_total
  • n_kalman: Number of Kalman samples
  • n_dr3: Number of dr3 samples.
  • n_dbox5: Number of dbox5 samples.
  • n_track: Number of track samples.
  • n_ok_3: Number of (track & sat_pix & ion_rad & dr3) samples
  • n_ok_5: Number of (track & sat_pix & ion_rad & dbox5) samples
  • n_mag_est_ok: Number of (track & ion_rad) samples
  • n_mag_est_ok_3: Number of (track & ion_rad & dr3) samples
  • n_mag_est_ok_5: Number of (track & ion_rad & dbox5) samples
  • f_dr3: Fraction of mag-est-ok samples with centroid residual < 3 arcsec((mag_est_ok & n_dr3)/n_mag_est_ok)
  • f_dbox5: Fraction of mag-est-ok samples with centroid within 5 arcsec box((mag_est_ok & n_dbox5)/n_mag_est_ok)
  • f_mag_est_ok: n_mag_est_ok_3/n_kalman. This is a measure of the fraction of time during an observation that a magnitude estimate is available.
  • f_mag_est_ok_3: n_mag_est_ok_3/n_kalman.
  • f_mag_est_ok_5: n_mag_est_ok_5/n_kalman.
  • f_ok: n_ok_5 / n_kalman. Same as f_ok_5
  • f_ok_3: n_ok_3 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting high-quality star centroids.
  • f_ok_5: n_ok_5 / n_kalman. This is a measure of the fraction of time during an observation that the Kalman filter is getting any star centroid at all. This includes measurements out to 5 arcsec box halfwidth, so potentially 7 arcsec radial offset.
