ACA Health Plots

datestartdatestop
2009:224:08:25:37.1262009:224:23:25:14.654


obsidstartstop
56898 2009:224:08:20:38.6742009:224:08:28:05.574
56897 2009:224:08:28:07.6242009:224:10:38:09.925
56896 2009:224:10:38:11.9752009:224:11:16:25.925
56895 2009:224:11:16:27.9752009:224:16:34:21.176
56894 2009:224:16:34:23.2262009:224:20:02:48.226
56893 2009:224:20:02:50.2762009:224:20:44:14.877
56892 2009:224:20:44:16.9272009:224:23:33:55.177

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
