ACA Health Plots

datestartdatestop
2010:084:04:31:02.1312010:084:17:14:14.009


obsidstartstop
56377 2010:084:04:26:12.9042010:084:04:33:17.254
56376 2010:084:04:33:19.3042010:084:06:07:00.405
56375 2010:084:06:07:02.4552010:084:07:01:34.255
56374 2010:084:07:01:36.3052010:084:13:50:02.006
56373 2010:084:13:50:04.0562010:084:14:39:38.606
56372 2010:084:14:39:40.6562010:084:17:31:15.757

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
