ACA Health Plots

datestartdatestop
2011:160:18:33:29.7442011:161:07:09:09.596


obsidstartstop
55368 2011:160:18:28:15.9162011:160:18:49:18.717
55367 2011:160:18:49:20.7672011:160:19:53:59.367
55366 2011:160:19:54:01.4172011:160:23:38:13.517
55365 2011:160:23:38:15.5672011:161:04:01:26.718
55364 2011:161:04:01:28.7682011:161:07:16:11.719

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
