ACA Health Plots

datestartdatestop
2013:130:15:03:20.0522013:131:02:36:51.980


obsidstartstop
53708 2013:130:14:57:55.9752013:130:15:15:07.125
53707 2013:130:15:15:09.1752013:130:17:24:32.526
53706 2013:130:17:24:34.5762013:130:20:43:27.626
53705 2013:130:20:43:29.6762013:130:21:46:40.127
53704 2013:130:21:46:42.1772013:130:23:08:17.577
53703 2013:130:23:08:19.6272013:131:00:14:59.177
53702 2013:131:00:15:01.2272013:131:03:04:39.478

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
