ACA Health Plots

datestartdatestop
2014:265:12:32:26.0742014:266:00:29:46.852


obsidstartstop
52457 2014:265:12:27:30.6972014:265:12:36:01.147
52456 2014:265:12:36:03.1972014:265:15:40:41.398
52455 2014:265:15:40:43.4482014:265:17:31:00.848
52454 2014:265:17:31:02.8982014:265:18:26:56.699
52453 2014:265:18:26:58.7492014:265:19:27:27.249
52452 2014:265:19:27:29.2992014:265:21:40:05.349
52451 2014:265:21:40:07.3992014:266:00:29:45.650

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
