ACA Health Plots

datestartdatestop
2015:170:04:21:15.1512015:170:19:23:35.654


obsidstartstop
51826 2015:170:04:16:20.7992015:170:04:24:51.249
51825 2015:170:04:24:53.2992015:170:07:02:38.149
51824 2015:170:07:02:40.1992015:170:11:39:29.300
51823 2015:170:11:39:31.3502015:170:16:34:33.101
51822 2015:170:16:34:35.1512015:170:19:38:40.552

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
