ACA Health Plots

datestartdatestop
2017:028:23:00:02.7592017:029:13:33:23.837


obsidstartstop
50349 2017:028:22:55:03.2822017:028:23:13:17.982
50348 2017:028:23:13:20.0322017:029:00:35:44.632
50347 2017:029:00:35:46.6822017:029:05:06:20.633
50346 2017:029:05:06:22.6832017:029:06:30:25.683
50345 2017:029:06:30:27.7332017:029:10:54:23.984
50344 2017:029:10:54:26.0342017:029:13:54:58.235

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
