ACA Health Plots

datestartdatestop
2017:042:04:31:14.6252017:042:18:49:58.303


obsidstartstop
50315 2017:042:04:26:02.8482017:042:04:33:29.748
50314 2017:042:04:33:31.7982017:042:07:16:36.449
50313 2017:042:07:16:38.4992017:042:11:04:25.849
50312 2017:042:11:04:27.8992017:042:12:43:43.150
50311 2017:042:12:43:45.2002017:042:15:29:15.400
50310 2017:042:15:29:17.4502017:042:18:49:59.151

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
