ACA Health Plots

datestartdatestop
2017:158:11:50:43.1082017:159:02:46:33.087


obsidstartstop
50030 2017:158:11:46:00.0312017:158:11:57:55.482
50029 2017:158:11:57:57.5322017:158:16:24:43.932
50028 2017:158:16:24:45.9822017:158:17:45:07.583
50027 2017:158:17:45:09.6332017:158:23:47:58.584
50026 2017:158:23:48:00.6342017:159:00:45:12.334
50025 2017:159:00:45:14.3842017:159:02:46:33.935

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
