ACA Health Plots

datestartdatestop
2017:182:06:38:17.6282017:182:22:06:15.631


obsidstartstop
49974 2017:182:06:33:36.6012017:182:06:42:33.701
49973 2017:182:06:42:35.7512017:182:11:04:47.452
49972 2017:182:11:04:49.5022017:182:15:30:20.053
49971 2017:182:15:30:22.1032017:182:18:03:22.004
49970 2017:182:18:03:24.0542017:182:18:56:29.754
49969 2017:182:18:56:31.8042017:182:20:11:45.904
49968 2017:182:20:11:47.9542017:182:22:06:15.454

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
