ACA Health Plots

datestartdatestop
2019:166:08:06:48.1852019:166:22:32:02.388


obsidstartstop
48110 2019:166:07:45:53.4082019:166:11:13:33.309
48109 2019:166:11:13:35.3592019:166:12:10:32.709
48108 2019:166:12:10:34.7592019:166:14:27:55.759
48107 2019:166:14:27:57.8092019:166:15:35:26.559
48106 2019:166:15:35:28.6092019:166:18:18:37.360
48105 2019:166:18:18:39.4102019:166:19:53:01.510
48104 2019:166:19:53:03.5602019:166:22:32:02.211

Plots of ACA housing temperature, CCD temperature, and DAC control level. Data is only available during perigee passes or other 8x8 ERs. Datestart and datestop correspond to the time range when 8x8 ACA telemetry is available for all required slots.
