ACA Health Plots |
| datestart | datestop |
|---|
| 2022:297:03:29:59.374 | 2022:300:13:59:57.243 |
|
| obsid | | start | stop |
|---|
| 45150 | | 2022:297:03:30:00.222 | 2022:297:08:48:40.573 |
| 45149 | | 2022:297:08:48:42.623 | 2022:297:10:27:37.374 |
| 45148 | | 2022:297:10:27:39.424 | 2022:297:14:05:58.925 |
| 45147 | | 2022:297:14:06:00.975 | 2022:297:14:51:27.475 |
| 45146 | | 2022:297:14:51:29.525 | 2022:297:15:22:47.325 |
| 45145 | | 2022:297:15:22:49.375 | 2022:297:16:36:37.375 |
| 45144 | | 2022:297:16:36:39.425 | 2022:297:18:04:25.875 |
| 45143 | | 2022:297:18:04:27.925 | 2022:297:19:36:01.926 |
| 45142 | | 2022:297:19:36:03.976 | 2022:297:21:07:40.026 |
| 45141 | | 2022:297:21:07:42.076 | 2022:298:03:06:35.278 |
| 45140 | | 2022:298:03:06:37.328 | 2022:298:09:11:39.529 |
| 45139 | | 2022:298:09:11:41.579 | 2022:298:11:08:44.879 |
| 62622 | | 2022:298:11:08:46.929 | 2022:298:14:03:16.280 |
| 45138 | | 2022:298:14:03:18.330 | 2022:298:20:02:11.531 |
| 45137 | | 2022:298:20:02:13.581 | 2022:299:02:07:19.883 |
| 45136 | | 2022:299:02:07:21.933 | 2022:299:06:58:56.634 |
| 45135 | | 2022:299:06:58:58.684 | 2022:299:12:57:51.885 |
| 45134 | | 2022:299:12:57:53.935 | 2022:299:19:03:02.287 |
| 45133 | | 2022:299:19:03:04.337 | 2022:299:23:54:39.038 |
| 45132 | | 2022:299:23:54:41.088 | 2022:300:02:04:24.938 |
| 45131 | | 2022:300:02:04:26.988 | 2022:300:03:25:07.038 |
| 45130 | | 2022:300:03:25:09.088 | 2022:300:05:32:58.139 |
| 45129 | | 2022:300:05:33:00.189 | 2022:300:06:21:27.089 |
| 45128 | | 2022:300:06:21:29.139 | 2022:300:08:25:06.040 |
| 45127 | | 2022:300:08:25:08.090 | 2022:300:09:49:58.240 |
| 45126 | | 2022:300:09:50:00.290 | 2022:300:11:20:40.990 |
| 45125 | | 2022:300:11:20:43.040 | 2022:300:13:59:58.091 |
Plots of ACA housing temperature, CCD temperature, and DAC
control level. Data is only available during perigee passes or other 8x8 ERs.
Datestart and datestop correspond to the time range when 8x8
ACA telemetry is available for all required slots.
